Toika Liisa floor loom

Toika Liisa loom: traditional countermarch loom from Finland

The Toika Liisa loom is a high-quality, handcrafted countermarch loom made of solid Finnish birch. With its sturdy construction and flexible features, it is suitable for a wide range of projects, from delicate, sheer fabrics to robust rugs. Thanks to its precise mechanics and durable materials, it is the ideal choice for ambitious weavers who value quality, ergonomics and reliability.

Key features:

• Shafts & treadles: 4, 8, 12 or on request up to 16 shafts, usually the same number of treadles
• Weaving widths: 80, 100, 120 or 150 cm weaving width
• Frame: Solid Finnish birch, sturdy plug and wedge connections
• System: Countermarch as standard, counterbalance (roller) available on request
• Beater: Choice of floor-standing or hanging beater at the same price
• Tension system: Precise gear system for fine adjustment of the warp tension

Floor-standing or hanging beater?

What matters is not so much the thread density as the type of fabric. If the fabric needs to be beaten very firmly, for example rugs or dense fabrics, the floor-standing beater is the better choice. Light fabrics such as fine scarves can also have a very high thread density. But since they are light and do not need a particularly strong beat, the hanging beater is often the more comfortable choice.

Scope of delivery:

• Liisa loom with floor-standing or hanging beater (your choice)
• Stainless reed 40/10 (10 dpi)
• Raddle with lid
• Robust metal temple
• Warp sticks & cross sticks
• Lacing rods & shaft rods
• Loom bench
• Rug shuttle 40 cm
• Shuttle 34 cm
• Worm gear for stepless warp advance
• Pre-cut Texsolv cord set for the Liisa loom
• 400 Texsolv heddles
• 50 warp sticks
• Beam apron with cord loops
• Rubber feet
• Sleying hook
• Cord needle
• Scissors holder
• Cork board for paper
• Assembly and operating instructions

Technical data:

• Dimensions (WxDxH):
  • Liisa 80: 117 x 136 x 153 cm
  • Liisa 100: 137 x 136 x 153 cm
  • Liisa 120: 157 x 136 x 153 cm
  • Liisa 150: 187 x 136 x 153 cm
• Weight:
  • Liisa 80: 100 kg
  • Liisa 100: 110 kg
  • Liisa 120: 120 kg
  • Liisa 150: 130 kg

Optional extensions

• Double warp or back beam
• Flying shuttle
• Sectional beam or additional beam
• Additional heddles
• Upgrade to the electronic control system (Toika ES system)

Why choose the Toika Liisa loom?

Robust & durable: High-quality craftsmanship in solid Finnish birch
Precise control: Finely adjustable tension for perfect weaving quality
Versatile: Ideal for light fabrics up to heavy rugs
Flexible: Different widths, shaft and treadle variants, floor-standing or hanging beater
Individually expandable: From sectional beam to electronic control

FAQs

Which beater is included?
When ordering, you choose between a floor-standing and a hanging beater at the same price.

Can I fine-tune the warp tension?
Yes, the gear system allows precise and comfortable adjustment of the tension from the seat.
